Southbend 4484DC-7R-LP 32" Liquid Propane Ultimate Restaurant Range - 271,000 BTU
Shop all Southbend Commercial Gas Range
- SKU:
- 4484DC-7R-LP
- MPN:
- 4484DC-7R
Select an Option
This product comes with warranty coverage. Warranty terms vary by product and part type. See full warranty details.
Commercial design services
Discover a whole new degree of kitchen customization with our proven idea-through-installation model. Learn more
Optimize kitchens with the Southbend 4484DC-7R-LP range: six burners, standard oven, cabinet base, 22.5" flue riser, stainless steel exterior, 6" legs, 271,000 BTU, CSA/NSF certified.
- 22.5" flue riser with hi-shelf
- Standard oven, cabinet base with rack
- 6" adjustable legs for flexibility
- 271,000 BTU gas output
- Stainless steel front, sides, shelf
- Six-burner cooktop with versatile burners
Weight735 LBS
Height59.5 (H)
Width48.63 (W)
Depth34 (D)
Base(1) Standard Oven, (1) Cabinet
Cook Top37.00
Cubic Volume70.9 Cu.Ft
Door Opening15.50"
Exterior FinishStainless steel
Flue Riser22.5 Flue Riser Standard
Legs6" Adjustable Legs
No of Burners6
Number of Racks1
Oven Bottom13.00"
Oven DoorSpring assisted, counterweight door
Oven Interior (WidthxDepthxHeight)26.00"Wx26.50"Dx14.00"H
TopBurners
Total BTU271,000 BTU
VentBackriser with hi-shelf
Voltage120
ManufacturerSouthbend
Amps5.9
Phase1
Hertz60
Control TypeManual
Power TypeLiquid Propane
Dimensions48 69 74
| Weight | 735 LBS |
|---|---|
| Height | 59.5 (H) |
| Width | 48.63 (W) |
| Depth | 34 (D) |
| Base | (1) Standard Oven, (1) Cabinet |
| Cook Top | 37.00 |
| Cubic Volume | 70.9 Cu.Ft |
| Door Opening | 15.50" |
| Exterior Finish | Stainless steel |
| Flue Riser | 22.5 Flue Riser Standard |
| Legs | 6" Adjustable Legs |
| No of Burners | 6 |
| Number of Racks | 1 |
| Oven Bottom | 13.00" |
| Oven Door | Spring assisted, counterweight door |
| Oven Interior (WidthxDepthxHeight) | 26.00"Wx26.50"Dx14.00"H |
| Top | Burners |
| Total BTU | 271,000 BTU |
| Vent | Backriser with hi-shelf |
| Voltage | 120 |
| Manufacturer | Southbend |
| Amps | 5.9 |
| Phase | 1 |
| Hertz | 60 |
| Control Type | Manual |
| Power Type | Liquid Propane |
| Dimensions | 48 69 74 |
