Southbend 4484EE-3TR-LP 60.75" Liquid Propane Ultimate Restaurant Range - 220,000 BTU
Shop all Southbend Commercial Gas Range
- SKU:
- 4484EE-3TR-LP
- MPN:
- 4484EE-3TR
Commercial design services
Discover a whole new degree of kitchen customization with our proven idea-through-installation model. Learn more
Southbend 4484EE-3TR-LP range offers 220,000 BTU, a 37" cooktop with burners, griddle, two ovens, stainless steel exterior, 6" legs, 22.5" flue riser, and cCSAus/CSA/NSF certifications.
- Stainless steel front, sides, shelf, 6" legs
- Two space-saver ovens, spring doors
- 22.5" flue riser, hi-shelf, oven racks
- 220,000 BTU output for high-capacity cooking
- 36" griddle, .500" thick plate
- 48" cooktop, 37" usable surface
Weight735 LBS
Height59.5 (H)
Width48.63 (W)
Depth34 (D)
Base(2) standard / space saver ovens
Cook Top37.00"
Cubic Volume70.9 Cu.Ft
Door Opening15.50"
Exterior FinishStainless steel
Flue Riser22.5 Flue Riser Standard
Legs6" Adjustable Legs
No of Burners2
Number of Racks1
Oven Bottom13.00"
Oven DoorSpring Assisted, Counterweight Door
Oven Interior (WidthxDepthxHeight)19.50"Wx26.50"Dx14.00"H
Plate Thickness.500" = 1/2"
TopBurners with Right Griddle
Total BTU220,000 BTU
VentBackriser with hi-shelf
Voltage120
ManufacturerSouthbend
Amps5.9
Phase1
Hertz60
Oven TypeGriddle
Control TypeManual
Power TypeLiquid Propane
Dimensions48 69 74
| Weight | 735 LBS |
|---|---|
| Height | 59.5 (H) |
| Width | 48.63 (W) |
| Depth | 34 (D) |
| Base | (2) standard / space saver ovens |
| Cook Top | 37.00" |
| Cubic Volume | 70.9 Cu.Ft |
| Door Opening | 15.50" |
| Exterior Finish | Stainless steel |
| Flue Riser | 22.5 Flue Riser Standard |
| Legs | 6" Adjustable Legs |
| No of Burners | 2 |
| Number of Racks | 1 |
| Oven Bottom | 13.00" |
| Oven Door | Spring Assisted, Counterweight Door |
| Oven Interior (WidthxDepthxHeight) | 19.50"Wx26.50"Dx14.00"H |
| Plate Thickness | .500" = 1/2" |
| Top | Burners with Right Griddle |
| Total BTU | 220,000 BTU |
| Vent | Backriser with hi-shelf |
| Voltage | 120 |
| Manufacturer | Southbend |
| Amps | 5.9 |
| Phase | 1 |
| Hertz | 60 |
| Oven Type | Griddle |
| Control Type | Manual |
| Power Type | Liquid Propane |
| Dimensions | 48 69 74 |
