Southbend 4604AD-2RR-NG 48.63" Natural Gas Ultimate Restaurant Range - 175,000 BTU
Shop all Southbend Commercial Gas Range
- SKU:
- 4604AD-2RR-NG
- MPN:
- 4604AD-2RR
Commercial design services
Discover a whole new degree of kitchen customization with our proven idea-through-installation model. Learn more
Southbend 4604AD-2RR-NG 48.63" natural gas range delivers 175,000 BTU with six burners and a left griddle. Stainless steel, 36" griddle, and 4-rack oven ensure high-volume service.
- 22.5" flue riser with hi-shelf included
- Standard oven with battery spark ignition
- 6" adjustable legs for leveling
- 175,000 BTU commercial cooking power
- Stainless steel front, sides, and shelf
- Six-burner cooktop with left 36" griddle
Weight1075 LBS
Height59.5 (H)
Width60.75 (W)
Depth44.5 (D)
Base(1) Standard Oven, (1) Convection Oven
Cook Top37
Cubic Volume132.3 Cu.Ft
Door Opening15.50"
Exterior FinishStainless steel
Flue Riser22.5 Flue Riser Standard
Legs6" Adjustable Legs
No of Burners6
Number of Racks4
Oven Bottom13.00"
Oven DoorSpring assisted, counterweight door
Plate Thickness.500" = 1/2"
TopBurners with Left Griddle
Total BTU175,000 BTU
VentBackriser with hi-shelf
Voltage120
ManufacturerSouthbend
Amps5.9
Phase1
Hertz60
Oven TypeRestaurant Range
Control TypeManual
Power TypeNatural Gas
Dimensions48 69 74
| Weight | 1075 LBS |
|---|---|
| Height | 59.5 (H) |
| Width | 60.75 (W) |
| Depth | 44.5 (D) |
| Base | (1) Standard Oven, (1) Convection Oven |
| Cook Top | 37 |
| Cubic Volume | 132.3 Cu.Ft |
| Door Opening | 15.50" |
| Exterior Finish | Stainless steel |
| Flue Riser | 22.5 Flue Riser Standard |
| Legs | 6" Adjustable Legs |
| No of Burners | 6 |
| Number of Racks | 4 |
| Oven Bottom | 13.00" |
| Oven Door | Spring assisted, counterweight door |
| Plate Thickness | .500" = 1/2" |
| Top | Burners with Left Griddle |
| Total BTU | 175,000 BTU |
| Vent | Backriser with hi-shelf |
| Voltage | 120 |
| Manufacturer | Southbend |
| Amps | 5.9 |
| Phase | 1 |
| Hertz | 60 |
| Oven Type | Restaurant Range |
| Control Type | Manual |
| Power Type | Natural Gas |
| Dimensions | 48 69 74 |
